Product Details:
|
| Salt Concentration:: | The Concentration Of Sodium Chloride 5% Or The 5% | Salt Spray Test Chamber:: | 270L,selectable |
|---|---|---|---|
| Certificate: | ISO9001:2008 | Design Criteria: | CNS, JIS, K5400, Z2371, ASTM |
| Spray Quantity: | 1.0~2.0 Ml / 80cm2 / Hr | Standards:: | ASTM B117, GB/T2423.17 |
| Brine Temperature: | 35°C±1°C | Test Chamber Temperature: | NSS ACSS 35±1°C CASS:50±1°C |
| Temperature Precision: | ±1°C | PH:: | 6.5~7.2 3.0~3.2 |
| High Light: | corrosion testing equipment,salt spray test machine |
||
Custom GB ASTM JIS IEC Salt Spray Corrosion Test Chamber with Touch Screen
HD-E808-60 Salt Spray Chamber.pdf
HD-E808-90 Salt Spray Chamber.pdf
HD-E808-120 Salt Spray Chamber.pdf
HD-E808-160 Salt Spray Chamber.pdf
Product Description:
Salt Spray Chamber adapted to the surface treatment of various materials, including paint, electroplating,
organic and inorganic coating, anode processing, antirust oil and so on, after these anti`corrosive treatment to test the corrosion resistance of their products.
Standards:
GB.10587-89, ASTM.B117-97, JIS H8502, IEC68-2-11, etc.
Specification:
|
Model |
HD-E808-60 |
HD-E808- 90 |
HD-E808-120 |
HD-E808-160 |
HD-E808-200 |
|
Work-space volume: |
108L (3.8 cu. ft.) |
270L (9.5 cu. ft.) |
600L (21 cu. ft.) |
800L (28 cu. ft.) |
1440L (50.8 cu. ft.) |
|
|
Dimensions |
||||
|
Workspace dimensions (WxDxH): |
60× 40× 45 cm (23.6" x 15.7" x 17") |
90× 60× 50cm (35" x 23.6" x 19.6") |
120× 100× 50 cm (47" x 39.3" x 19.6") |
160× 100× 50 cm (63" x 39.3" x 19.6") |
200× 120× 60 cm (78.7" x 47" x 23.6") |
|
Exterior dimensions (WxDxH): |
107× 60× 118 cm (42" x 23.6" x 46") |
141× 88× 128cm (55.5" x 34.6" x 50") |
190× 130× 140 cm (74.8" x 51" x 55") |
230× 130× 140 cm (90.5" x 51" x 55") |
270× 150× 150 cm (106" x 59" x 59") |
|
|
Performance |
||||
|
Temperature Range: |
RT+5°C ～55°C (RT+-41°F ～ 131°F) |
||||
|
Temperature Fluctuation: |
± 0.5° C |
||||
|
Temperature Gradient: |
± 2° C |
||||
|
Spray Quantity |
1.0~2.0 ml / 80cm2 / hr |
||||
|
Power |
AC220V, 1Ø ,30A |
||||
|
Safety Protection |
Multiple Safety Protection Devices |
||||
|
Accessories |
Testing Salt/ Measuring tank/ Equipment each 1 set |
||||
|
Standard |
CNS: 3627, 3385, 4159, 7669, 8886; JIS: D0201, H8502, K5400, Z2371; ISO: 3768, 3769, 3770; ASTM: B117, B268, MIL-STD-810F |
||||
Characteristics:
Has insufficient water feature can automatically replenish the water level.
Precision glass nozzle (PYREX) 4000 to ensure that no obstruction between crystallization.
Control device are on the same board, easy to operate, and can glance for.
With dual over-temperature protection, water shortage alert, ensure safe use.
Digital display temperature is taken, SSR control, accuracy of 0.1 ℃.
Mining trough direct steam heating method, heating speed, shorten the standby time.
Spray tower with conical diffuser, a guide ring fog, adjust the volume, and even off the fog and other
functions.
Operation interface:
