Product Details:
|
| Humiture Range: | 30-98%RH | Rainfall Cycle: | 1-240min |
|---|---|---|---|
| Certificate: | ISO9001: 2008 | Warranty Period: | 12 Months |
| Studio Size: | 95Dx95Wx90Hcm | Box Material: | Stainless Steel SUS304# |
| Insulation Materials: | Superfine Glass Fabric | Control System: | Germany KLOCKNER-MOELLER Progammable Controler |
| Gas Processing: | Dischager For Fector And Harmful Gas | Use Environment: | 5°C~+30°C, ≤85%R.H |
| Use: | Xenon Accelerated Weathering Tester | ||
| High Light: | ozone test chamber,xenon test chamber |
||
Environment Accelerated Aging Chamber Xenon Test Chamber With SUS304
Product Introduction
Xenon Aging Chamber is analogue terrestrial solar radiation environment, widely used to determine the electrical, electronic products shell, leather and other light on the atmospheric environment adaptability; also be used to examine the effect of solar radiation on the ground equipment and components produced (thermal, mechanical, , chemical, electrical, etc.)
Key Features
Remarkably Simple User Interface
AUTOCAL Calibration
Full Spectrum Xenon Lamps
Long-Life Optical Filters
Programmable Water Spray
SOLAR EYE Irradiance Control
Precision Temperature Control
Versatile Specimen Mounting
Relative Humidity Control
Auxiliary Structure
Seal: double high-temperature high tensile seal between the door and the cabinet in order to ensure that the test area
Door handle: no reaction door handle, easier to operate
Moves the sample holder: Sample holder rely installation box at the bottom of the linear reciprocating drive system for moving up and down
Casters: bottom of the machine can be fixed with high quality PU wheels
Specifications
| Model | HD-711L Xenon Lamp Aging Chamber |
| Inner Box Size (D×W×H) | 950×950×900mm |
| Outside Dimension (D×W×H) | 1300×1500×1900mm |
| Humiture Range | (RT+10)~70°C; 30~98%RH |
| Humiture uniformity | ± 2°C; ± 3%RH |
| Rainfall time | 1~9999min, adjustable |
| Rainfall cycle | 1~240min, interval is adjustable |
| Xenon lamp light | xenon long-arc lamp, 6KW±10%, 290-800nm, 1000W/m2±200 |
| Heating/humidifying power | 2.0KW/2.0KW |
| Sample spinning machine speed | 1~5r/ min (adjustable) |
| Sample and xenon lamp distance | 300~375mm |
| Box material | Stainless Steel SUS304# |
| Insulation materials | Superfine heat insulation cotton |
| Insulation body | Superfine glass fabric |
| Circulation system | Single cycle, centrifugal fan |
| Control system | Germany KLOCKNER-MOELLER progammable controler |
| Gas processing | dischager for fector and harmful gas |
| Power | AC380V, three phase five wire, 10KW |
| Use environment | 5°C~+30°C, ≤85%R.H |
| Standard features | 1. Filtering screen viewing window; 2.Moistureproof lamp |
| Security Protection | Security device for circuit break, |
| high pressure of the compressure, high temperature alarm |
Simple to Maintain
We believe that just because a product is technical, it doesn’t have to be hard to understand or difficult to maintain and repair. Instead of complicating our tester designs by loading them with extra or unnecessary features, we put our engineering effort into keeping things simple. Subsystems are modular, easy to troubleshoot and even easier to replace.
Operation
Xenon lamps Accelerated Aging Chamber are extremely simple to operate. Specimen mounting and evaluations are simplified with specially designed specimen holders. Programming is intuitive. All models are completely automated and can operate continuously, 24 hours per day, 7 days per week.
Simple to Afford
Xenon lamps Accelerated Aging Chamber were specifically designed to have the lowest total cost of ownership in the industry. Their low purchase price, low lamp price, and low operating costs set a new standard for lightfastness testing. Now even the smallest lab can afford xenon arc weathering and lightstability testing.
Xenon Lamp Aging Chamber Maintenance
1, any time to maintain a neat appearance;
2. Do not place objects on top of the machine to heat parts of Lima Da and control;
3, xenon lamp aging chamber after long-term use, spare parts, motor blower unit, wheel deceleration devices, if abnormal noise, should be checked, and pay attention to regular cleaning fuel;
4, electrical components such as over-temperature phenomena, must be checked immediately causes;
5, after each use, a xenon lamp aging test chamber should be kept clean to prevent corrosion;
6, the control cabinet clean-up once a month to prevent excessive dust, affecting the normal operation of equipment;
7. After the test is complete, you should turn off the main power, water stains wipe clean indoor work, try to keep the chamber in a dry environment;
8, the electrical components on the control panel, such as the need to exchange failure occurs, Do not indiscriminate demolition ensure xenon lamp aging chamber life.
