Digital High Temperature MOR Machine for Refractory Testing

$Digital High Temperature MOR Machine for Refractory Testing$ $Digital High Temperature MOR Machine for Refractory Testing$

$Digital High Temperature MOR Machine for Refractory Testing$

Large Image : Digital High Temperature MOR Machine for Refractory Testing

Product Details:

Place of Origin:	Guangdong, China (Mainland)
Brand Name:	Haida
Certification:	ISO,CE
Model Number:	60095-HD

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiable
Packaging Details:	Export wooden case
Delivery Time:	15 days after order confirmed
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	30 Sets per Month Haida

Contact Now

Digital High Temperature MOR Machine for Refractory Testing

Description

Display Device:	PC	All Weight:	2800kg
Available Tensile Stroke:	900mm	Unit Switchover:	G, KG, N, LB
Weight:	500 Kg	Test Speed:	0.1~300mm/min
Usage:	Tension Material Tension Strength Tester	Resolution:	1/100,000
Test Space Height:	500 Mm	Crosshead Travel:	1000 Mm
Force Reading:	Kgf, Ibf, N, KN, T Etc	Load Capacity:	5-200kg
Crosshead Speed Accuracy:	±0.2%	Grip:	Tensile Grip, Tear Force Grip
Dimensions:	1200 Mm X 800 Mm X 1800 Mm
Highlight:	Refractory Testing MOR Machine , MOR Machine for refractory

60095-HD Digital High Temperature MOR Machine

Product Specifications

Attribute	Value
Display Device	PC
All Weight	2800kg
Available Tensile Stroke	900mm
Unit Switchover	G, KG, N, LB
Weight	500 kg
Test Speed	0.1~300mm/min
Usage	Tension Material Tension Strength Tester
Resolution	1/100,000
Test Space Height	500 mm
Crosshead Travel	1000 mm
Force Reading	kgf, Ibf, N, KN, T etc
Load Capacity	5-200kg
Crosshead Speed Accuracy	±0.2%
Grip	Tensile grip, Tear force grip
Dimensions	1200 mm x 800 mm x 1800 mm

Product Description

The 60095-HD Digital High Temperature MOR Machine complies with GB3002-2017, GB/T13243-1991, YB/T 5201-93, JB/T 2980.2-1999, and HB/T 5352.1-2004 standards. This precision instrument tests high temperature flexural strength of refractory products, carbon-containing refractory materials, dense refractory castables, ceramic rollers, silicate products, and casting shell materials. Featuring computer connectivity for automated testing and data processing, it offers stable force application, easy maintenance, and reliable results.

Maximum temperature options: 1400℃ or 1600℃
Maximum load options: 1000N, 10000N, or 20000N
Sample size compatibility with multiple industry standards
Precise temperature control: ±1℃ accuracy
Computer integration for automated control, data processing, and report generation
Power options: 380V, 8KW or 12KW
Heating elements: Silicon carbon rod (1400℃) or silicon molybdenum rod (1600℃)
Automatic sample feeding mechanism for continuous testing of 4-6 samples per heating cycle

$Digital High Temperature MOR Machine for Refractory Testing 0$
