|Place of Origin:||China|
|Minimum Order Quantity:||1 set|
|Packaging Details:||each set protected with resin fiber and PP film, then put into Strong wooden case with operation man|
|Delivery Time:||20 days after order confirmed|
|Payment Terms:||L/C, T/T, D/A, D/P, Western Union, MoneyGram|
|Supply Ability:||300 sets per month|
|Sensor:||Celtron Load Cell||Capacity:||1000,2000,3000,5000kg|
|Test Speed:||0.1-300mm/min (adjustable )||Power:||1ø,AC220V, 50HZ|
tensile testing equipments,
tensile strength tester
ASTM Used Pull Test Equipment Rubber Testing Machine For Wire , Cable
Estimated Packaging Dimensions: (W*D*H) 910*820*2210mm
Power supply source: single-phase, 220V±10%, 50/60Hz (can be appointed)
Estimated Gross Weight: 420kg
|Load cell brand||
Germany brand load cell for high accuracy
5000kg (1000,2000kg are optional)
|Load accuracy||0.5% F.S|
|Control system||PC with windows 7 system|
|Motor||Panasonic servo motor w/AC variable speed drive system, high-precision mechanical ball screw rod|
|Force reading||kgf, Ibf, N, KN, T etc|
|Vertical test space||1100mm including fixture|
|Horizontal test space||≤400mm|
|Test speed||0.1~300mm/min (adjustable)|
|Curves display||Load- elongation, Elongation-time, Time-elongation, Stress-strain|
|Data display||Max. force, speed, sample information, strength(Kpa, Mpa, N/mm, N/mm2) etc…|
Upper and lower limit switches
Load sensor with automatic retreat
1. Tested sample: laminated materials, wood, leather, rubber & plastic, metal material, etc.
2. Different test with different grips: tensile, peel, tear, heat seal, adhesive, bend and open force.
3. Deformation under defined load: Test deformation under defined load of tested sample
4. Load under defined deformation: Test load under defined deformation of tested sample
5. Software can issue word/excel report with results for max. force, elongation, tensile strength, peel strength, tear strength, compression strength, etc.
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-con.
Why choose us?
1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.
2.Excellent After sale Service:
18 months warranty. Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.
Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
How to Contact Us?
Please Send your inquiry Details in the below for our quotation,Click "Send" Now!
Contact Person: Mr. Liang
