UV Light Accelerated Aging testing Chamber Accelerated Weathering Laboratory

UV Light Accelerated Aging testing Chamber Accelerated Weathering Laboratory
UV Light Accelerated Aging testing Chamber Accelerated Weathering Laboratory
UV Light Accelerated Aging testing Chamber Accelerated Weathering Laboratory UV Light Accelerated Aging testing Chamber Accelerated Weathering Laboratory UV Light Accelerated Aging testing Chamber Accelerated Weathering Laboratory UV Light Accelerated Aging testing Chamber Accelerated Weathering Laboratory

Large Image :  UV Light Accelerated Aging testing Chamber Accelerated Weathering Laboratory

Product Details:
Place of Origin: china
Brand Name: Haida
Certification: ISO9001: 2008, CE, ...
Model Number: HD-E802-1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
Delivery Time: 15 days after order confirmed
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300 sets per month

UV Light Accelerated Aging testing Chamber Accelerated Weathering Laboratory

Description
Temperature Control: PID SSR Control Certificate: ISO9001: 2008, CE, ...
Lamp Power: 40W/Piece Materials: Inside And Outside SUS#304 Stainless Steel
Temperature Uniformity: ±2°C Distance From Sample To Lamp: 50±2mm (adjustable)
Testing Time: 0~999H, Adjustable Control Mode: Balance Temperature Humidity Control (BTHC)
Controller: Korean TEMI 880 Programmable Controller
High Light:

ozone test chamber

,

accelerated aging calculator

UV Light Accelerated Aging Chamber Accelerated Weathering Laboratory





UV Accelerated Weathering Tester.pdf



About Product



UV Aging Test chamber can simulate the sun, rain and dew to damage the material, UV machine using UV lamp simulate the effect of sunlight, cold rain and dew. Being tested materials are placed in a certain environment which the light and moisture are alternation. The materials are tested for several days or weeks, you can know the damage of material at outside for several months or several years.



Damage types include: bleaching, discoloration, loss of light, power, crack, turbidity, bubble-based, embrittlement, strength decline and oxidation.



UV Light Accelerated Aging Chamber Accelerated Weathering Laboratory can get the results of damage after several days or weeks which is equal to expose to outside for a few months. The damages include fading, discoloration, brightness down, powder, crack, blur,brittle,strength decreases and oxidation. It provides the reference with testing data for improvement of existing materials, or to assess the impact of changes in product durability and other aspects.



Function:



Meet Specifications

* Meet customer requirements

* Stay ahead of government regulations



Prevent Field Failures

* Improve quality and durability

* Enhance reputation

* Assure product performance



Gain a Competitive Edge

* Save on material costs

* Expand product lines

* Enter new markets

* Outrun the competition



How it Works

UV Light Accelerated Aging testing Chamber Accelerated Weathering Laboratory 0



Product Specification:



Inner chamber Size

1140mm×400 mm×500 mm

Customized

Outside dimension

1340mm×530 mm×1400 mm

Materials

SUS#304 stainless steel ( Internal and external)

Temperature range

RT+10~70℃

Temperature uniformity

±1℃

Temperature fluctuation

±0.5℃

Temperature control

PID SSR control

Humidity range:

≥90%RH

Controller

Korean TEMI 880 programmable controller

Control mode

Balance temperature humidity control (BTHC)

Test cycle setting

Illumination, condensation and water spray test cycle is programmable

Lamp power

40W/Piece

Distance from sample to lamp

50±3mm (adjustable)

Centre distance between the lamp

70mm

Irradiance

1.0W/cm2

Wavelength ultraviolet light

UV-A: 315-400nm

UV-B: 280-315nm

Lamp lifetime

1600hrs

Effective irradiation areas

640×1140mm

Illumination temperature range

50℃~70℃

Condensation temperature range

40℃~60℃

Black panel temperature

30℃~80℃

Standard Specimen Size

75×290mm (24pcs) or 75x150mm (48pcs), or can be customized

Testing time

0~999H, adjustable

Power

AC220V±10%, 50/60Hz, single phase, 5KW

Protection system

Overload short circuit protection, over temperature protection, water

lacking protection



TEMI 880 Controller

uv test

Programmable LCD controller, can do cyclic test with temp, humid, water spray and condensation.



UV lamps

uv test

UV-A and UV-B lamps for option



Sample Holder

uv test

Test specimens are mounted on both the front and back side of the UV Tester, providing a large sample

capacity.

Sample holder can be customized.
