Xenon Accelerated Aging Test Chamber Air-cooled Control System

Xenon Accelerated Aging Test Chamber Air-cooled Control System
Xenon Accelerated Aging Test Chamber Air-cooled Control System
Xenon Accelerated Aging Test Chamber Air-cooled Control System Xenon Accelerated Aging Test Chamber Air-cooled Control System Xenon Accelerated Aging Test Chamber Air-cooled Control System Xenon Accelerated Aging Test Chamber Air-cooled Control System Xenon Accelerated Aging Test Chamber Air-cooled Control System

Large Image :  Xenon Accelerated Aging Test Chamber Air-cooled Control System

Product Details:
Place of Origin: China
Brand Name: Haida
Certification: ISO
Model Number: HD-E711
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time: 20 days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 300 Sets per Month Haida

Xenon Accelerated Aging Test Chamber Air-cooled Control System

Description
Product Name: Xenon Aging Test Chamber Internal Chamber Material: SUS 304 # Stainless Steel, Anti-rust
External Chamber Material: Cold-rolled Steel With Spray Chamber Humidity Range: 55%~90% RH
Chamber Temperature: 35℃~90℃
High Light:

ozone test chamber

,

accelerated aging calculator

Xenon Accelerated Aging Test Chamber Air-cooled Control System



Xenon Aging Test Chamber - Air cooled.pdf



Product Description:



Xenon aging test chamber can simulate the full sunlight spectrum of xenon arc lamp to reproduce the destructive light waves in different environments, to provide the appropriate environmental simulation and accelerated test for scientific research, product development and quality control.



Main Parameter:



Item Specification
Internal Dimension (W*D*H) 700*500*600mm
External Dimension (W*D*H) 1350*1300*1850mm
Internal chamber material SUS 304 # Stainless Steel, anti-rust
External chamber material Cold-rolled steel with spray
Chamber humidity range 55%~90% RH
Chamber temperature 35℃~90℃
Black panel temperature 45℃~95℃, adjustable
Temperature uniformity ≤±3℃
Filter Window glass filter / daylight filter
Light source Air cooled long arc xenon lamp
Xenon lamp power 1.8KW * 3pcs = 5.4KW
Irradiance strength 0.51W/m2@340nm
Control system

LCD programmable controller,

Auto display irradiance, capacity: 100 groups program, 99 cycles.

Illumination time 1~999 hours, adjustable
Water spray system

Water spray time 999 minutes settable

Interval spray time, 1~240 minutes settable

Sample holder Stainless steel, 1pc

Distance from sample

holder to lamp

250~300mm
Heating Nickel-chromium alloy electric heater
Humidification power Stainless steel surface evaporative humidifier
Insulation materials Supper fine glass fiber
Temperature sensor PT100 high precision sensor
Air circulation system Stainless steel centrifugal rotor vane to improve the uniformity of temperature and humidity
Standard accessories

Xenon lamp x 3pcs;

Humidification cotton x 5pcs;

English user manual x 1pc;

Operation video x 1pc



Xenon Aging Test Chamber Features:

1, using full-spectrum xenon lamp LED;

2, a variety of alternative filtration system;

3, rain shower function;

4, relative humidity control.

5, chamber air temperature control system;

6, irregular shape of the sample holder;

Xenon Accelerated Aging Test Chamber Air-cooled Control System 0
