Single Column Cotton Yarn Strength Testing Machine Fabric Testing Equipment

Single Column Cotton Yarn Strength Testing Machine Fabric Testing Equipment

    • Single Column Cotton Yarn Strength Testing Machine Fabric Testing Equipment
    • Single Column Cotton Yarn Strength Testing Machine Fabric Testing Equipment
  • Single Column Cotton Yarn Strength Testing Machine Fabric Testing Equipment

    Product Details:

    Place of Origin: china
    Brand Name: Haida
    Certification: ISO9001: 2008, CE, ...
    Model Number: HD

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiation
    Packaging Details: Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
    Delivery Time: 15 days after order confirmed
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 300 sets per month
    Contact Now
    Detailed Product Description
    Working Mode: CRE Control Model: LCD Display(can Be Connect Computer)
    Load Measure Range: 5000CN Load Accuracy: ±0.1%
    Test Times: 300 Times Speed: 20~1000mm/min( Stepless Adjustable)
    Elongation Accuracy: ±1% Gripper: Single Gripper
    Clamping Distance: 40~1000mm(adjustable)

    Cotton yarn strength Testing Machine



    Product description

    This Yarn strength Tester is use to determine the breaking force and break elongation test for single yarn made of cotton , wool , jute ,core-spun yarn etc .

    Test standard:GB/T 3916,ISO 2062



    Technical parameter

    Working Mode CRE
    Control model LCD display(can be connect computer)
    Load Measure Range 5000cN
    Load accuracy ±0.1%
    test times 300 times
    Speed 20~1000mm/min( Stepless adjustable)
    Elongation accuracy ±1%
    gripper Single gripper
    Clamping distance 40~1000mm(adjustable)
    Power AC220V±10% 50HZ 0.1kw
    Elongation test range 0~250mm(when clamping distance is 500mm)
    Outside dimension 680X350X960mm





    Single Column Cotton Yarn Strength Testing Machine Fabric Testing Equipment



    Single Column Cotton Yarn Strength Testing Machine Fabric Testing Equipment



    Single Column Cotton Yarn Strength Testing Machine Fabric Testing Equipment



    Single Column Cotton Yarn Strength Testing Machine Fabric Testing Equipment



    Our company Introduction:

    HAIDA INTERNATIONAL is a professional manufacturer of various kinds of testing equipments over 24 years. HAIDA products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and applicable to all scientific research units, quality inspection institutions and academic fields.





    Why choose us?

    1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.



    2.Excellent After sale Service:
    18 months warranty. Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.



    3.Commitment:
    We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.



    4.Good Packaging:

    Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.

    HD-B609A-S Universal Test Machine.pdf
