Digital Pendulum Impact Tester for Film and Paper Packaging

Large Image : Digital Pendulum Impact Tester for Film and Paper Packaging

Product Details:

Place of Origin:	China
Brand Name:	Haida
Certification:	CE、ISO
Model Number:	5086-HD

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time:	20 days after order confirmed
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	300 Sets per Month

Contact Now

Digital Pendulum Impact Tester for Film and Paper Packaging

Description

Function:	Compression Test,Paper Tube Compressive Strength Test,Burst Tester,tensile Test,Paper Testing Instrument	Name:	Paper Cup Tube Compressive Strength Tester,Paper Testing Instrument Paper Gsm Tester/ Bursting Strength Tester,paper Testing Instrument
Display:	LCD,Digital Display	Units Switch:	Kgf,N.( Optional),Lbf
Steel Ball:	16mm * 20	Frequency Range:	60-300 Round/min Adjustable
Drive Mode:	Power-driven	Indicating Method:	Digital
Test Space:	600×800×800mm(can Be Customized)	Drop Height Range:	400-1500mm
Dimension:	530(L)490(D) 960(H)mm	Measurement Range:	0~199
Customized Support:	OEM ODM	Tear Length:	43mm
Test Area:	7.3 Cm²	Operation Mode:	PC
Drop Height:	400~1300 Mm	Lifting Speed:	50-300mm / Min, Set Fixed Speed
Test Items:	Bursting Strength, Compression Strength, Tearing Strength, Puncture Resistance, Friction Coefficient, Etc.	Accuracy:	±0.5% Of Reading Value
Precision:	≤0.5%
Highlight:	Film Paper Packaging Tester , Digital Pendulum Impact Tester

EQUIPMENT DETAILS FOR 5086- HD FILM PENDULUM IMPACT TESTER

Product Specifications

Attribute	Value
Function	Compression test, Paper Tube Compressive Strength Test, Burst tester, Tensile test, Paper Testing Instrument
Display	LCD, Digital display
Units switch	Kgf, N. (Optional), Lbf
Steel Ball	16mm * 20
Frequency Range	60-300 round/min adjustable
Drive Mode	Power-driven
Test Space	600×800×800mm (can be customized)
Drop Height Range	400-1500mm
Dimension	530(L)490(D)960(H)mm
Measurement Range	0~199
Customized Support	OEM ODM
Tear Length	43mm
Test Area	7.3 cm²
Operation Mode	PC
Lifting Speed	50-300mm/min, set fixed speed
Test Items	Bursting strength, compression strength, tearing strength, puncture resistance, friction coefficient, etc.
Accuracy	±0.5% of reading value
Precision	≤0.5%

Product Description

The 5086-HD Film Pendulum Impact Tester uses a standard pendulum head and weighted pendulum arm to measure impact resistance of plastic films, sheets, and composite films. It evaluates impact toughness for materials including PE/PP composite films, aluminized films, aluminum-plastic composites, nylon films, and materials used in food/medicine packaging. Also suitable for testing pendulum impact resistance of paper and paperboard products.

Testing Principle

The instrument uses a semi-spherical punch to impact and break samples at controlled speeds, measuring the energy consumed during impact. This energy measurement provides the anti-pendulum impact energy value for film samples.

Design Standards

Complies with GB/T8809 and ASTM D3420 standards.

Technical Parameters

Item	Description
Capacity	3J
Scale value	0.01J
Pendulum swing radius	R280 mm
Pendulum angle	90°
Impact speed	2.5m/S
Impact head size	Φ12.7 mm
Sample holder diameter	Φ60, Φ89mm
Sample size	100 X 100 mm
Dimensions	780 X 250 X 600 mm
Weight	35kg

About Haida

Haida products serve diverse industries including paper goods, packaging, printing, adhesives, textiles, footwear, leather, environmental materials, toys, hardware, electronics, plastics, and rubber. Our testing equipment meets UL, ASTM, JIS, GB, and ISO standards and is widely used by research institutions, quality inspection agencies, and academic facilities.
