30KN Sine Wave Vibration Shaker Table for Structural Testing 5-2600Hz

Large Image : 30KN Sine Wave Vibration Shaker Table for Structural Testing 5-2600Hz

Product Details:

Place of Origin:	China
Brand Name:	Haida
Certification:	ISO
Model Number:	HD-G826

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time:	20 days after order confirmed
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:	300 Sets per Month

Contact Now

30KN Sine Wave Vibration Shaker Table for Structural Testing 5-2600Hz

Description

Sine Force (peak):	30KN	Shock Force (peak):	60KN
Frequency Range:	5～2,600 Hz	Displacement (continuous):	100 Mm
Max. Velocity:	1.8 M/s	Max. Acceleration:	75 G
1st Order Resonant Frequency:	2,400 Hz
Highlight:	Sine Wave Vibration Shaker Table , 30KN Sine Wave Vibration Shaker , Structural Testing Sine Wave Vibration Shaker

Sine Wave and FM Frequency Range Vibration Shaker Table Systems

Structural Strength Testing Equipment with Full Computer Control

Key Specifications

Attribute	Value
Sine force (peak)	30KN
Shock force (peak)	60KN
Frequency range	5～2,600 Hz
Displacement (continuous)	100 mm
Max. Velocity	1.8 m/s
Max. Acceleration	75 G
1st order resonant frequency	2,400 Hz

Laboratory Material Transport Simulation Vibration Testing Equipment

Electro-dynamic Vibration Testing Equipment is widely used in defense, aviation, aerospace, communications, electronics, automobiles, and home appliance industries. This system is designed for early fault detection, simulating actual working conditions, and structural strength testing.

System Components

Component	Specifications
Shaker (Model# EDM-2000)	Armature Diameter: 445 mm Allowable eccentric moment: >500 Nxm Max. Payload: 500 kg Dimensions: 1,330×860×1,250 mm
Power Amplifier (Model# VSA-H323A)	Amplifier output: 30 kVA SNR: >65 dB Dimensions: 800×900×2,100 mm
Horizontal Slip Table (Model# 30ST-600M)	Dimensions: 600×600 mm Frequency limit: 2,000 Hz High pressure oil-film bearing for better uniformity
