High-Precision Prototype Injection Molding Machine For Custom Plastic Parts

Name: High-Precision Prototype Injection Molding Machine For Custom Plastic Parts
Brand: Hai Da Labtester
SKU: HD-A839-2
Price: 7,500.00 USD
Availability: InStock

All Products

Lab Test Machines
(65)

Environmental Test Chamber
(114)

Tensile Test Machine
(182)

Flammability Testing Equipment
(24)

Temperature Humidity Chamber
(42)

Accelerated Aging Chamber
(59)

IP Test Equipment
(39)

Corrosion Test Chamber
(41)

ISTA Packaging Testing
(34)

Paper Packaging Testing Instruments
(24)

Furniture Testing Equipment
(63)

Needle Testing Machine
(10)

Textile Testing Equipment
(40)

Vibration Shaker Table Systems
(13)

Baby stroller Testing Machine Series
(6)

Optical Measuring Machine
(23)

Battery Test Equipment
(19)

Rubber Plastic Test Equipment
(29)

Chemical Analysis Machine
(9)

Electronic Cigarette Test Machine
(10)

Certification

Customer Reviews

Yes we received the machine last week. This Machine was nice, and thank the after-sales serives, was very professional.

—— Peter Maas

On behalf of the company to visit your factories and companies, the technical staff is very professional and patient, I think I would be happy to cooperate with you again.

—— Steve Hubbard

I'm Online Chat Now

High-Precision Prototype Injection Molding Machine For Custom Plastic Parts

Large Image : High-Precision Prototype Injection Molding Machine For Custom Plastic Parts

Product Details:

Place of Origin:	China
Brand Name:	Haida
Certification:	CE,,ISO
Model Number:	HD-A839-2

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiation
Packaging Details:	each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time:	20 days after order confirmed
Payment Terms:	L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability:	300 Sets per Month

Contact Now

High-Precision Prototype Injection Molding Machine For Custom Plastic Parts

Description

Temperature Range:	RT To 450℃ (±3℃) [Maximum 450℃]	Plunger Diameter [mm]:	35mm
Maximum Compression Stroke [mm]:	150mm	Heating Chamber Size [mm]:	35 * 110
Maximum Injection Volume:	40g	Injection Pressure:	1 Ton
Injection Time:	0-9999s [Adjustable]	Mold Cavity Structure:	Removable Mold Cavity, Effectively Prevents Material Cross-contamination
Safety Protection:	Protective Door + Safety Grating	Machine Weight [kg]:	35kg
Power:	1000W	Voltage:	220V/60Hz
Air Supply:	0.6MPa	Control Method:	Pneumatic
Overall Dimensions [mm]:	600 * 660 * 1400	Max Mold Installation Size:	200 * 200 * 210
Highlight:	Custom Plastic Parts Injection Molding Machine , Prototype Injection Molding Machine , High Precision Injection Molding Machine

Prototype Molding Machine

Application:

The injection molding prototype machine is a mechanical device. It is usually composed of an injection system, a mold clamping system, a pressure transmission system, an electrical control system, a lubrication system, a heating and cooling system, a safety monitoring system, etc.
The injection system is one of the most important components of the injection molding machine. Generally, there are three main forms: plunger type, screw type, and screw pre-plastic plunger injection type. The most widely used one is the screw type. Its function is to heat and plasticize a certain amount of plastic within a specified time in one cycle of the injection molding machine, and then inject the molten plastic into the mold cavity through the screw at a certain pressure and speed.

High-Precision Prototype Injection Molding Machine For Custom Plastic Parts 0

Main technical parameter:

Parameter	Specification
Temperature Range	RT to 450℃ (±3℃) [Maximum 450℃]
Plunger Diameter [mm]	35mm
Maximum Compression Stroke [mm]	150mm
Heating Chamber Size [mm]	35 * 110
Maximum Injection Volume	40g
Injection Pressure	1 Ton
Injection Time	0-9999s [Adjustable]
Mold Cavity Structure	Removable mold cavity, effectively prevents material cross-contamination
Safety Protection	Protective door + Safety grating
Max Mold Installation Size	200 * 200 * 210
Machine Weight [kg]	35kg
Power	1000W
Voltage	220V/60Hz
Air Supply	0.6MPa
Control Method	Pneumatic
Overall Dimensions [mm]	600 * 660 * 1400
