Place of Origin: | China |
Brand Name: | haida |
Certification: | ISO |
Model Number: | HD-A501-900 |
Minimum Order Quantity: | 1set |
---|---|
Price: | Negotiable |
Packaging Details: | each set protected with resin fiber and PP film, then put into Strong wooden case with operation man |
Delivery Time: | 20 days after order confirmed |
Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow |
Supply Ability: | 300 Sets per Month |
Product Name: | Carton Compression Testing Machine | Unit (switchable): | Kg, Lb, N |
---|---|---|---|
Capacity (optional): | 2T | Load Resolution: | 1/100,000 |
Load Accuracy: | ≤0.5% | Power: | 1ø, 220v/ 50Hz |
High Light: | ista package testing,package testing equipment |
LCD Carton Compression Test Machine For ISTA Packaging Testing
About the machine:
Carton compression testing machine is suitable for electronics, electrical appliances, electrical wires, hardware, bicycles, handbags, food, medicine, shoes, furniture, etc. that are packed in corrugated boxes. It is suitable for packaging of corrugated boxes, honeycomb board boxes, etc. Pressure resistance, deformation, stacking test. It also takes into account the compression tests of containers such as plastic drums (edible oil, mineral water), paper drums, cartons, paper cans, and container drums (IBC drums).
Specifications:
Model | HD-A501-900 |
Unit (switchable) | Kg, Lb, N |
Capacity (optional) | 2T |
Load Resolution | 1/100,000 |
Stroke (exclude the grips) | 400 mm |
Load Accuracy | ≤0.5% |
Test Space (LxWxH) | 800x1000x1000mm |
Speed of Compression | 10 ± 3 mm/min |
Operation Mode | PC |
Report Items | Serial number, Peak value, Average value, Designated holding pressure value; all memorable |
Structure | AC Frequency Conversion Motor ( Taiwan); Imported screw rod ;4 sensors; LED display |
Dimension (L×W×H) | 2370×1500×2100mm (can be custom made) |
Power | 1ø, 220v/ 50Hz |
Weight | Approx. 850kg |
Safety Devices | Overload protection, overvoltage protection & limited position protection device |
Standard | TAPPI-T804, JIS-20212, GB4857.3.4, ASTM-D642 |
Features
Carton Compression Testing Equipment
Using a single-screen operation; do not need to switch the screen;
With three languages in Simplified Chinese, Traditional Chinese and English, the software interface can be switched easily;
Adopting windows platform, and all the parameter settings can be processed in the dialog box, and it operates easily;
The pattern of Test reports can be self-designated; test data can be displayed directly in the main screen;
Choosing translational, comparative mode at the same time to make a number of curve data comparison;
With a variety of measurement units, Measure In Imperial & Metric are switchable;
With self-return & auto-correction function;
With automatic magnification function, in order to achieve the most appropriate size of the graphics;
With the user-defined Test methods; with experimental data analysis function;
It can do test of compression, bending, pressure holding & fatigue.
With high precision and accuracy and reasonable price, it can test the crush instantaneously and stop automatically.
Design criteria:
TAPPI-T804,JIS-20212,GB4857.3.4, ASTM-D642, QB/T1048, BS EN ISO 12048, GB/T4857.16, GB/T8167, GB/T8168, GB/T4857.3,GB/T4857.4
