Precision Paper Testing Equipment / Cardboard Ring Crush And Edge Compressive Tester

Precision Paper Testing Equipment /  Cardboard Ring Crush And Edge Compressive Tester
Precision Paper Testing Equipment /  Cardboard Ring Crush And Edge Compressive Tester Precision Paper Testing Equipment /  Cardboard Ring Crush And Edge Compressive Tester Precision Paper Testing Equipment /  Cardboard Ring Crush And Edge Compressive Tester Precision Paper Testing Equipment /  Cardboard Ring Crush And Edge Compressive Tester

Large Image :  Precision Paper Testing Equipment / Cardboard Ring Crush And Edge Compressive Tester

Product Details:
Place of Origin: China
Brand Name: Haida
Certification: ISO
Model Number: HD-A513-2
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time: 20 days after order confirmed
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability: 300 Sets per Month

Precision Paper Testing Equipment / Cardboard Ring Crush And Edge Compressive Tester

Description
Name: Ring Crush And Edge Compressive Tester Capacity: 10, 20, 50, 100, 200 Kg
Resolution: 1/100,000 Precision: < 0.5%
Dimension: 570×415×730 Mm Power: AC220V, 1.5A
Highlight:

paper and packaging material testing instruments

,

paper bursting strength tester

Cardboard Ring Crush And Edge Compressive Tester ISTA Packaging Testing




The usage
Cardboard ring crush tester can do a full range of tests, which include Ring Crush Testing, Flat Crush testing, Edge Compressive Testing, Adhensive Strength Testing and other general compression tests, to a variety of materials like paper, packaging materials, etc. It is a multi-functional testing equipment.


The main technical parameters are as follows

Capacity (Optional) 10, 20, 50, 100, 200 kg
Resolution 1/100,000
Precision < 0.5%
Operation Mode Computer
Display Mode LCD
Platen 100×100 mm or depending on the diameter of the flat crush sample
Compressed Space 500 mm
Platen Parallelism ± 0.05 mm
Ring Crush Sample 152×12.7 mm
Edge Crush Sample 25×100 mm
Test Speed 12.7 mm/min
Dimension (L×W×H) 790×510×1060 mm
Weight Approx. 51 kg
Power AC220V, 1.5A
