Product Details:
|
Usage: | Constant Temperature And Humidity Testing Machine | Temp. Range: | -70°C~150°C |
---|---|---|---|
Humid. Range: | 10~ 98 Percent R.H. | Temp. & Humid. Accuracy: | ± 0.3°C; ± 2 Percent R.H |
Temp. & Humid. Regularity: | ± 1°C; ± 3 Percent RH | Resolution: | 0.01°C, 0.1 Percent, P.I.D Control |
Heating Up: | -40°C ~ +100°C Within 45 Min | Heating Down: | 20°C~ -20°Cwithin 40min |
Interior Dimension(W×D×H): | 100×100×80cm | Exterior Dimension(W×D×H): | 145x190x135cm |
Interior Material: | Stainless Steel Plate(SUS304) | Exterior Material: | Stainless Steel Plate(SUS304) |
Insulation: | Rigid Foam | Display: | LCD |
Weight: | Approx. 600 Kg | Power: | AC220V±10 Percent 50/60Hz |
Use: | Temperature Humidity Climatic Chamber | ||
High Light: | Temperature And Humidity Controlled Cabinets,Constant Temperature And Humidity Chamber |
Constant Temperature Humidity Test Chamber LCD Display Stainless Steel Plate
Temperature and humidity chamber.pdf
1. Features
Constant Temperature Humidity Test Chamber LCD Display Stainless Steel Plate is applied to test the materials in heat-resistance, cold-resistance, dry-resistance, moisture-resistance. It is simple to operate and program easy to edit. It can show the set values and operative time.
International Applications
HD series chambers meet international test performance standards. The units can be installed around the world for consistent testing at different facilities, supported by Haida Group and our cooperation prater in Australia, Dubai, India, Malaysia, Turkey and Vietnam. And our chambers feature two levels of overheat protection, and one levels of overcool protection. The system controller provides alarm messages with specific troubleshooting help to quickly resume testing.
2. Specifications of
Temp/Humidity |
HD-E702-100-4 |
HD-E702-150-4 |
HD-E702-225-4 |
|
|
HD-E702-408-4 |
HD-E702-800-4 |
HD-E702-1000-4 |
|
Temp-only |
HD-E702-100T-4 |
HD-E702-150T-4 |
HD-E702-225T-4 |
|
|
HD-E702-408T-4 |
HD-E702-800T-4 |
HD-E702-1000T-4 |
|
Temperature Range: |
-40°C ~150°C |
|||
Cooling Capacity |
~ 2 kW at -20°C |
~ 2.5 kW at -20°C |
~ 4.5 kW at -20°C |
|
~ 5.5 kW at-20°C |
~ 8 kW at -20°C |
~ 8.5 kW at - -20°C |
||
Heating System |
~ 5 kW |
~ 5 kW |
~ 5.5 kW |
|
~6.5 kW |
~ 8.5 kW |
~ 9 kW |
||
Temperature Fluctuation: |
±0.5°C |
|||
Temperature Gradient: |
±0.5°C~±0.2°C |
|||
Heating Rate†: |
≥3℃ / min average ( Advance model 5 – 15 ℃ / min) |
|||
Cooling Rate†: |
≥1℃ / min average (Advance model 5 - 15℃ / min) |
|||
Humidity Range: |
10%~95%RH (Ref to Normal Humidity Range Diagramed) |
|||
Humidity Fluctuation: |
±1.5%RH~±2.0%RH |
|||
Humidity Gradient: |
±3%RH |
|||
Dimensions |
||||
Workspace dimensions |
500x400x500 HD-E702-100 |
600x500x500 HD-E702-150 |
750x500x600 HD-E702-225 |
|
|
850x650x800 HD-E702-800 |
1000x1000x800 HD-E702-800 |
1000x1000x1000 HD-E702-1000 |
|
Exterior dimensions |
1400x850x1050 |
1500x950x1050 |
1650x950x1150 |
|
|
1750x1050x1350 |
1900x1450x1350 |
1900x1450x1550 |
|
Site Requirements |
||||
Electrical Supply: |
208V 3Ø 60Hz or 230V 3Ø 60Hz (customer specific) |
|||
Humidity Water |
Distilled Water |
|||
Condensate Drain: |
1/2" hose connection (gravity drain) |
Range – 70 to 150°C
Temp/Humidity |
HD-E702-100-7 |
HD-E702-150-7 |
HD-E702-225-7 |
|
|
HD-E702-408-7 |
HD-E702-800-7 |
HD-E702-1000-7 |
|
Temp-only |
HD-E702-100T-7 |
HD-E702-150T-7 |
HD-E702-225T-7 |
|
|
HD-E702-408T-7 |
HD-E702-800T-7 |
HD-E702-1000T-7 |
|
Temperature Range: |
-70°C ~150°C |
|||
Cooling Capacity |
~ 2.5 kW at -50°C |
~ 3 kW at -50°C |
~ 5 kW at -50°C |
|
~ 6.5 kW at-50°C |
~ 8.5 kW at -50°C |
~ 9 kW at - -50°C |
||
Heating System |
~ 5 kW |
~ 5 kW |
~ 5.5 kW |
|
~6.5 kW |
~ 8.5 kW |
~ 9 kW |
||
Temperature Fluctuation: |
±0.5°C |
|||
Temperature Gradient: |
±0.5°C~±0.2°C |
|||
Heating Rate†: |
≥3℃ / min average ( Advance model 5 – 15 ℃ / min) |
|||
Cooling Rate†: |
≥1℃ / min average (Advance model 5 - 15℃ / min) |
|||
Humidity Range: |
10%~95%RH (Ref to Normal Humidity Range Diagramed) |
|||
Humidity Fluctuation: |
±1.5%RH~±2.0%RH |
|||
Humidity Gradient: |
±3%RH |
|||
Dimensions |
||||
Workspace dimensions |
500x400x500 HD-E702-100 |
600x500x500 HD-E702-150 |
750x500x600 HD-E702-225 |
|
|
850x650x800 HD-E702-800 |
1000x1000x800 HD-E702-800 |
1000x1000x1000 HD-E702-1000 |
|
Exterior dimensions |
1400x850x1050 |
1500x950x1050 |
1650x950x1150 |
|
|
1750x1050x1350 |
1900x1450x1350 |
1900x1450x1550 |
|
Site Requirements |
||||
Electrical Supply: |
208V 3Ø 60Hz or 230V 3Ø 60Hz (customer specific) |
|||
Humidity Water |
Distilled water |
|||
Condensate Drain: |
1/2" hose connection (gravity drain) |
3. Performance of Constant Temperature Humidity Test Chamber LCD Display Stainless Steel Plate
Get a performance evaluation to help provide the suitable chambers to you.
For better assurance of performance for your temperature and humidity cycling application, Haida can provide a guaranteed performance calculation based on your submitted requirements.
Please use these questions as below as a guide to define your test plan. You can then give this information to our lab consultant or email to us, for review by our lab consultant. A recommended model with appropriate refrigeration size will provide to you.
System & Performance Options
(Normal Humidity Range Diagramed)
Constant Temperature Humidity Test Chamber LCD Display Stainless Steel Plate view
