Product Details:
|
| Description:: | Salt Spray And Tempera | Certificate: | ISO9001:2008 |
|---|---|---|---|
| Design Criteria: | CNS, JIS, K5400, Z2371, ASTM | Spray Quantity: | 1.0~2.0 Ml / 80cm2 / Hr |
| Spray Volume:: | 0.5~3.0 | Brine Temperature: | 35°C±1°C |
| Test Chamber Temperature: | NSS ACSS 35±1°C CASS:50±1°C | Service:: | Customization Service |
| Power: | 1A C220V | ||
| High Light: | corrosion testing equipment,salt spray test machine |
||
1.0~2.0 ml / 80cm2 / hr ASTM Salt Spray Corrosion Test Chamber High precision P.I.D.Control
Product image & Description:
1.0~2.0 ml / 80cm2 / hr ASTM Salt Spray Corrosion Test Chamber High precision P.I.D.Control through the examination of the material and its ability to salt spray corrosion protective layer, and a protective layer similar process quality compared to the same time assess the ability of certain product resistance to salt spray corrosion; this product is suitable for parts and components, electronic element, protective layer, and salt spray corrosion testing of industrial products, metal materials.
Features:
1.Automatic add water when water shortage, with a group of manually water
2.Special glass nozzle, guarantee non-crystalline block for 4000 hours
3.With dual over-temperature protection, water shortage warning, ensure safety use
4.Temperature device adopts digital display, SSR control, precision is 0.1 centigrade degree
5.Chamber adopts direct steam heating method, fast warming, shortening standby time
6.Spray tower attached cone diffuser, with functions of directional mist, adjustable mist, and uniformity fog lamp.
Precautions
1, after the end of each test, the switch should open the oil-water separator, the oil water put the net, and wipe clean.
2, if a long-term test should not saturated the water put the net, in normal use, should periodically replace the water in the saturator.
3, not long-term, if re-do the test, and to deal with all the electrical supply, gas supply system to make a specific system check, after the failure to prevent the boot.
4, found dirt clogging the nozzle, remove the nozzle promptly with alcohol, xylene, or 1: 1 hydrochloric acid wash or superfine wire careful and clear, not damage the wall of the nozzle opening, so as not to affect the spray quality.
Main technical parameters: 1.0~2.0 ml / 80cm2 / hr ASTM Salt Spray Corrosion Test Chamber High precision P.I.D.Control
| Model | HD-60A-1 | HD-90A-1 | HD-120A-1 |
| Inner box size: (L×W×H) cm |
60×40×45 | 90×60×50 | 120×100×50 |
| Outside box size: (L×W×H)cm |
107×60×118 | 141×88×128 | 190×130×140 |
| Equipment material: | Both internal and external material is using imported P.V.C rigid plastic board; the case cover is using transparent rigid plastic board P.V.C. | ||
| Temperature range: | 35°C~55°C | ||
| Temperature fluctuations: | ≤±0.5°C | ||
| Temperature uniformity: | ≤±2°C | ||
| Temperature precision: | ±1°C | ||
| Test chamber temperature | NSS ACSS 35±1°C CASS:50±1°C | ||
| Saturated air barrel temperature: | NSS ACSS 47±1°C CASS 63±1°C | ||
| Brine temperature: | 35°C±1°C | ||
| Spray quantity: | 1.0~2.0 ml / 80cm2 /hr | ||
| PH: | NSS ACSS6.5~7.2 CASS 3.0~3.2 | ||
| Lab volume: | 108L | 270L | 600L |
| Brine tank capacity: | 15L | 25L | 40L |
| Power: | 1AC220V,10A | 1AC220V,15A | AC 1,220V,30A |
| Multiple safety protection devices: | Water shortage/ over temperature / phase protection | ||
| Standard accessories: | Test salt, measure bucket, tool etc 1 set | ||
