Electronic Thermal Shock Chamber Hot ,Cold Temperature Test Equipment

Electronic Thermal Shock Chamber Hot ,Cold Temperature Test Equipment

    • Electronic Thermal Shock Chamber Hot ,Cold Temperature Test Equipment
    • Electronic Thermal Shock Chamber Hot ,Cold Temperature Test Equipment
    • Electronic Thermal Shock Chamber Hot ,Cold Temperature Test Equipment
    • Electronic Thermal Shock Chamber Hot ,Cold Temperature Test Equipment
    • Electronic Thermal Shock Chamber Hot ,Cold Temperature Test Equipment
  • Electronic Thermal Shock Chamber Hot ,Cold Temperature Test Equipment

    Product Details:

    Place of Origin: China
    Brand Name: Haida
    Certification: CE,,ISO
    Model Number: HD-E703

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiation
    Packaging Details: Strong Wooden Case
    Delivery Time: 15 Days After Order
    Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability: 75 Piece / Pieces Per Month
    Contact Now
    Detailed Product Description
    Usage: High And Low Temperature Thermal Shock Test Chamber High Temp. Exposure Range*1: +60~ To +200°C
    Temp. Heat Up Time*3: Ambient Temp. To +200°C Within 30min Temp. Pull Down Time*3: Ambient Temp. To -65°C Within 70min
    External Material: Cold-rolled Rust-proofed Steel Plate Cooler: Stainless Steel Welded Plate Heat Exchanger
    Power Supply: AC380V, 50/60Hz, Three Phase , 30A Cooling Water Supply Pressure*6: 02~0.4Mpa
    High Light:

    environmental testing equipment

    ,

    environmental test chamber

    Electronic Thermal Shock Chamber Hot / Cold Temperature Test Equipment



    Electronic Thermal Shock Chamber Hot ,Cold Temperature Test Equipment 0Thermal Shock Chamber.pdf



    Description:

    Electronic Hot and Cold Temperature Shock Simulate Test Machine is divided into high temperature area, low temperature area and test area three parts, each area is a unique insulation structure, so doing hot and cold impact test. And by the degree of high temperatures and very low temperatures in a continuous environment can tolerate at the moment, that is, in the shortest time test their chemical or physical damage due to thermal expansion and contraction caused. Suitable objects include metal, plastic, rubber, electronics and other materials can be used as a basis for improvement of their products or reference





    Fuctions

    High-temperature impact test or low-temperature impact test, the maximum time is up to 9999 minutes, the most cycle time is up to 9999 times. The machine can be automatically or manually cycle the impact or selectively set the two areas or three areas to impact of hot and cold. It used binary cooling system that is very effectiveness for cooling, the cooling system is divided into the air-cooled and water-cooled. It also can be connected with a computer, but the record instrument is only for optional purchase. Color LCD touch-control operation interface with Chinese and English, easy to operate.



    Thermal Shock Chambers Operating: pretreatment, initial testing, testing, recovery, and finally detected.





    Features
    •Meets MIL-STD 202F, Method 107G, Conditions A, B, C, and F
    MIL-STD 883, Method 1010.7, Conditions A, B, C, and F
    •Solid-state overtemperature / undertemeperature protection
    •Electric open-air nichrome wire heater elements supported by
    ceramic insulators
    •Two open ended finned LN2 cooling coils
    •Centrifugal type blower wheel with external mounted motor
    •Pneumatically activated carriage transport system with up to
    six stainless steel mesh product baskets
    •Test chamber drain with Type 1/4" FPT connection
    •Door switches for each chamber




    Air conditioning system
    ·  the air control: forced ventilation circulation, balance thermostat method (BTC). This method not only refers to the case of the cooling system for continuous operation, the control system according to the temperature set point of the heater to control the output of the results by automatically calculating PID output, and ultimately achieve a dynamic equilibrium.
    ·  the air circulating means: built between the air circulation fan duct and the long axis of stainless steel, the use of energy efficient refrigerators and regulation system, by effective and efficient heat exchange ventilator, to achieve the purpose of the temperature change. By adjustable air outlet adjusting bolt, thereby significantly improving the chamber temperature uniformity;
    ·  the air cooling method: multi-stage diaphragm air heat exchanger.
    ·  the air heating: Watkins quality nickel chrome electric heater.





    Specifications of Electronic Hot and Cold Temperature Shock Simulate Test Machine:



    System

    Two-zone test by means of damper switching

    Three-zone chamber

    Model

    HD-E703-50A/HD-E703-50W

    HD-E703-100A/HD-E703-100W

    Customized

    Performance

    Test area

    High temp. exposure range*1

    +60~ to +200°C

    Low temp. exposure range*1

    -65to 0 °C

    Temp. fluctuation *2

    ±1.8°C

    Hot chamber

    Pre-heat upper limit

    +200°C

    Temp. heat up time*3

    Ambient temp. to +200°C within 30min

    Cold chamber

    Pre-cool lower limit

    -65°C

    Temp. pull down time*3

    Ambient temp. to -65°C within 70min

    Temp. recovery (2-zone)

    Recovery conditions

    Two-zone: High temp. exposure +125°C 30 min, Low temp. exposure -40°C 30 min; Specimen 6.5 kg (specimen basket 1.5kg)

    Temp. recovery time

    Within 10 min.

    Construction

    External material

    Cold-rolled rust-proofed steel plate

    Test area material

    SUS304 stainless steel

    Door*4

    Manually operated door with unlock button

    Heater

    Strip wire heater

    Refrigeration unit

    System*5

    Mechanical cascade refrigeration system

    Compressor

    Hermetically sealed scroll compressor

    Expansion mechanism

    Electronic expansion valve

    Refrigerant

    High temp side:R404A, Low temp side R23

    Cooler

    Stainless steel welded plate heat exchanger

    Air circulator

    Sirocco fan

    Damper driving unit

    Air cylinder

    Fittings

    Cable port with diameter 100mm on the left side (right side and tailor made diameter size are available as options), specimen power supply control terminal

    Inside dimensions (W x H x D)

    350 x 400 x 350

    500 x 450 x 450

    Customized

    Test area capacity

    50L

    100L

    Customized

    Test area load

    5 kg

    10 kg

    Customized

    Outside dimensions (W x H x D)

    1230 x 1830 x 1270

    1380 x 1980 x 1370

    Customized

    Weight

    800kg

    1100kg

    N/A



    Utility requirements



    Allowable ambient conditions

    +5~30°C

    Power supply

    AC380V, 50/60Hz, three phase , 30A

    Cooling water supply pressure*6

    02~0.4Mpa

    Cooling water supply rate*6

    8m³ /h

    Operating cooling water temp. range

    +18 to 23 °C

    Noise Level

    70 dB or lower



    Thermal Shock Chambers composed of

    · thermal shock chambers structural forms: thermal shock chambers chamber using integrated forms of composite structure, both located in the upper chamber by a high-temperature tank, located in the lower portion of the cryogenic tank, located in the rear of the cabinet and the refrigeration unit is located after the left side of the electrical control panel composed of cabinet (system).
    · thermal shock chambers outer box material: high-quality cold-rolled steel sheet, the surface for electrostatic spraying.
    · thermal shock chambers inside walls Material: SUS304 stainless steel, corrosion-resistant, easy to clean, nice.
    · insulation materials: high-quality ultra-fine glass fiber cotton, imported nonflammable PU.
    · sample holder: static stainless steel sample holder.
    · window: On the box (hot box) opened the door to a 350 × 250mm electric moisture barrier coating temperature observation window.
    · cable threading hole: diameter 50MM cable conduit opening in the middle of the test sample holder box.
    · sample holder bearing: ≥50Kg.



    Notes



    · If the high-temp exposure range lower limit + 60°C is required or the low temp exposure range lower limit -60°C, please select the “ambient-temperature exposure” option



    · If the temp fluctuation need to below ±1.8°C please select the “Low temp fluctuation package”



    · Temperature heat-up/pull down time are applicable only during independent chamber operation



    · If the automatically operated sliding door required, please select the “Automatically door package”



    ·  Air-cooled condenser / Water-cooled condenser both available



    ·  Apply on water-cooled condenser only





     Safety Devices of Hot and Cold Temperature Shock Simulate Test Machine:

    1)Hot chamber overheat protection switch

    2)Cold chamber overheat protection switch

    3)Air circulator overload alarm

    4)Refrigerator high/low pressure protector

    5)Compressor temperature switch

    6)Air pressure switch

    7)Fuse

    8)Water suspension relay ( water-cooled specification only)

    9)Compressor circuit breaker

    10)Heater circuit breaker

    11)Test area overheat/overcool protector

    12)Air purge valve



    Daily maintenance
    · hot and cold shock me a long shutdown is not used regularly every half power, power time is not less than one hour, and related spare parts and testing equipment is functioning properly.


    · hot and cold shock boxes should be cleaned regularly evaporator: cleanliness levels because the test is different, in the forced air circulation effect, will gather a lot of dust particles and other small objects on the evaporator should be cleaned regularly.


    · low-temperature chamber circulation fan, condenser fan and clean balance correction: cleaning and evaporator is similar because of different working environment chamber, circulating fan, will gather a lot of dust and other small particles on the object condenser fan should regular cleaning.


    · hot and cold shock box device To move preferably at Paddy ASHDOWN Lai instrumentation technician guidance, in order to avoid damage to the equipment, such as customer self relocation, must have a professional electrician before turning on power to confirm correct operation of the circuit, or will burned equipment related components.





    Control



    Electronic Thermal Shock Chamber Hot ,Cold Temperature Test Equipment 1

    (Color LCD interactive touch-screen system)



    Operation and settings simplified by the use of a touch-screen LCD display (instructions displayed on-screen). At-aglance confirmation of test patterns, test area temperatures, temperature cycles, and trend graph displays.



    Setting

    Interactive key input by touch panel

    Display

    LCD (5.7 inches)

    Temperature control function

    Test area: exposure temp.

    Hot chamber: pre-heating temp.

    Cold chamber: pre-cooling temp.

    PID control

    Preset temperature range

    High temperature: 60 to200’C

    Low temperature: -78 to 0’C

    Setting resolution

    1’C

    Input

    Thermocouple type T (Copper/Copper-Nickel)

    Setting and indication ranges

    Preset time: 0 min. to 99 hours and 59 min.

    Preset cycle: 1 to 9,999 cycles

    Accessory function

    Timer preset

    Overheat/ overcool protection

    Power failure/ recovery selection

    Temperature recovery time setting

    Program memory

    Automatic power shut-off

    Programmed time display

    Test completion mode selection

    Trend graph

    Alarm history display

    Sensor calibration

    RS-232/ USB communication
