Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117,

Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117,
Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117,
Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117, Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117, Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117, Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117, Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117,

Large Image :  Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117,

Product Details:
Place of Origin: china
Brand Name: Haida
Certification: ISO,CE,.......
Model Number: HD-E808
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual and video inside.
Delivery Time: 15 days after receive the order
Payment Terms: D/P, Western Union, MoneyGram
Supply Ability: 300 sets months

Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117,

Description
PH: NSS ACSS6.5~7.2 CASS 3.0~3.2 Power: 1A C220V
Certificate: ISO9001:2008 Design Criteria: CNS, JIS, K5400, Z2371, ASTM
Spray Quantity: 1.0~2.0 Ml / 80cm2 / Hr Warranty Period: 12 Months
Brine Temperature: 35°C±1°C Test Chamber Temperature: NSS ACSS 35±1°C CASS:50±1°C
Temperature Precision: ±1°C Color: White
High Light:

salt fog testing

,

salt spray test machine

Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine





Product Description:



Salt Spray Chamber adapted to the surface treatment of various materials, including paint, electroplating,

organic and inorganic coating, anode processing, antirust oil and so on, after these anti`corrosive treatment to test the corrosion resistance of their products.





Specification:



Model

HD-E808-60

HD-E808-

   90

HD-E808-120

HD-E808-160

HD-E808-200

Work-space

volume:

108L

(3.8 cu. ft.)

270L

(9.5 cu. ft.)

600L

(21 cu. ft.)

800L

(28 cu. ft.)

1440L

(50.8 cu. ft.)



 Dimensions

Workspace

dimensions

(WxDxH):

60× 40× 45 cm

(23.6" x

15.7" x 17")

90×

60× 50cm

(35" x

23.6" x 19.6")

120×

100× 50 cm

(47" x

39.3" x 19.6")

160×

100× 50 cm

(63" x

39.3" x 19.6")

200×

120× 60 cm

(78.7" x

47" x 23.6")

Exterior

dimensions

(WxDxH):

107× 60× 118 cm

(42" x

23.6" x 46")

141×

88× 128cm

(55.5" x

34.6" x 50")

190×

130× 140 cm

(74.8"

x 51" x 55")

230×

130× 140 cm

(90.5" x

51" x 55")

270×

150× 150 cm

(106"

x 59" x 59")



Performance

Temperature

Range:

RT+5°C ~55°C

(RT+-41°F ~ 131°F)

Temperature

Fluctuation:

± 0.5° C

Temperature

Gradient:

± 2° C

Spray

Quantity

1.0~2.0 ml / 80cm2 / hr

Power

AC220V, 1Ø ,30A

Safety

Protection

Multiple Safety Protection Devices

Accessories

Testing Salt/ Measuring tank/ Equipment

each 1 set

Standard

CNS: 3627, 3385, 4159, 7669, 8886; JIS: D0201, H8502,

K5400, Z2371; ISO: 3768, 3769, 3770; ASTM: B117, B268,

MIL-STD-810F





Characteristics:



Has insufficient water feature can automatically replenish the water level.



Precision glass nozzle (PYREX) 4000 to ensure that no obstruction between crystallization.



Control device are on the same board, easy to operate, and can glance for.



With dual over-temperature protection, water shortage alert, ensure safe use.



Digital display temperature is taken, SSR control, accuracy of 0.1 ℃.



Mining trough direct steam heating method, heating speed, shorten the standby time.



Spray tower with conical diffuser, a guide ring fog, adjust the volume, and even off the fog and other

functions.





Box structure
     1, high-temperature aging room with floor cabinet structure: the studio is located in the right part of the cabinet unit, since the chamber shape is wide, can be part of the electrical control unit placed in the cabinet, the operator panel is located in front of the cabinet unit. 0.6 color steel shell with cabinets, insulation material is flame-retardant rigid polyurethane foam, the thickness of 100mm.
     2, the electronic control unit cabinet: put in the right rear of the studio, specifically set up maintenance and overhaul wicket. Unit cabinet sound-absorbing panels, while the interior is equipped with extra-thick honeycomb and absorbing sponge absorbing rubber around, in order to achieve maximum noise reduction purposes.
     3, cabinet door: A single door structure, the chamber door sealed with silicone rubber, high temperature resistance, aging resistance, good sealing performance. Inside and outside the door can be opened
     4, box observation window: In order to facilitate observation of the test chamber, the hollow resistive film multilayer glass observation window materials are composed of anti-frost heating glass. The bottom of the form observed from the ground height 750mm.
     6, the lighting device: the test chamber is provided with two 40W / 36V moisture-proof, explosion-proof lighting, you can manually switch control directly, avoiding the middle of the housing area of ​​the sample.
     7, the bottom of the box: the bottom of the studio from the ground height of about 200mm; the floor is moderately inclined, floor layout inside the box several ribs to the bottom plate carrying capacity ≤1 tons.





Operation interface:



Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117, 0Intelligent Touch Screen Corrosion Test Chamber Salt Spray Test Machine ASTM B117, 1
